SPECS
- neck type
- AZ Oval CS-TECH WOOD 1pc Roasted Birdseye Maple neck
- top/back/body
- Ash body
- fretboard
- S-TECH WOOD Roasted Birdseye Maple fretboardMother of Pearl dot inlay
- fret
- Jumbo Stainless Steel fretsPrestige fret edge treatment
- number of frets
- 22
- bridge
- Gotoh® T1702B bridge
- string space
- 10.5mm
- neck pickup
- Seymour Duncan® Lari Basilio (S) neck pickupPassive/Alnico
- middle pickup
- Seymour Duncan® Lari Basilio (S) middle pickupPassive/Alnico
- bridge pickup
- Seymour Duncan® Lari Basilio (H) bridge pickupPassive/Alnico
- factory tuning
- 1E,2B,3G,4D,5A,6E
- strings
- D'Addario® EXL110
- string gauge
- .010/.013/.017/.026/.036/.046
- nut
- Bone nut
- hardware color
- Gold
-
NECK DIMENSIONS
-
- Scale :
- 648mm/25.5"
- a : Width
- 42mm at NUT
- b : Width
- 56.4mm at 22F
- c : Thickness
- 20.5mm at 1F
- d : Thickness
- 22.5mm at 12F
- Radius :
- 228mmR to 305mmR COMPOUND
-
-
SWITCHING SYSTEM
-
CONTROLS
-
OTHER FEATURES
- Hardshell case included
- Gotoh ® Magnum Lock machine heads w/H.A.P.
- dyna-MIX9 switching system w/Alter Switch
- Luminlay side dots
Features
Oval C S-TECH WOOD Roasted Birdseye Maple neck
The S-TECH special roasted treatment increases the wood's stability, durability, water resistance and tolerance of temperature changes. The neck is sealed with an oil finish which helps make it feel similar to a well-played guitar neck.
Gotoh® Magnum Lock w/H.A.P. machine heads
GOTOH® MAGNUM LOCK® machine heads have an established reputation for tuning stability. Its H. A. P® (Height Adjustable Post). system allows for the adjustment of string posts for the appropriate tension of each string.
S-TECH WOOD Roasted Birdseye Maple fretboard
The S-TECH special roasted treatment provides a superior attack, a well-balanced tone and a rich sustain. In order to achieve supreme neck grip comfort, the fretboard edge is finished with a smooth curve.
Compound Radius Fretboard (228mm to 305mm)
Offering the best of both worlds, the digitized compound radius fretboard is built to enhance both smooth chording and lead work in the upper register.
Seymour Duncan® Lari Basilio S-S-H pickups
Gotoh® T1702B tremolo
The T1702B tremolo bridge provides quick response and improved articulation. The 10.5mm string spacing allows for easy picking across strings and its snap-in construction makes it easy to load a tremolo arm. The tremolo block and saddles are made of brass, facilitating better overall resonance.
dyna-MIX9 switching system with Alter Switch
The dyna-MIX 9 offers nine sound variations and can switch between humbucker and single coil modes with just a flick of the mini switch. One mode even simulates a humbucking sound from the combination of two single coil pickups.
Luminlay side dot inlays
The Luminlay side dot position marks make it easy for players to see fretboard position marks when performing on dark stages.
